Detecto EH-544-185-AC Echelon 4 x 4 ft Legal For Trade Floor Scale with AC Adapter 5000 x 1 lb |
|
| Cardinal Scale’s Echelon EH series floor scales provide exceptional performance in light industrial and NTEP legal-for-trade applications for warehouses, logistics operations, processing plants, and shipping/receiving departments. Ideally suited for pallet, drum, and package weighing, the Echelon’s checkered carbon steel deck tread-plate with powder-coat paint handles rugged industrial weighing use. more ... |
|
Industrial Scales >
Floor Scales >
0 lb to 5000 lb
|
|
|
|
This Item Contains the following items
|
|
|
|
|
Features
Cardinal Scale’s Echelon EH floor scales provide exceptional performance in light industrial and NTEP legal-for-trade applications for warehouses, logistics operations, processing plants, and shipping/ receiving departments. Ideally suited for pallet, drum, and package weighing, the Echelon’s checkered carbon steel deck tread-plate with powder-coat paint handles rugged industrial weighing use. The EH series features 4-ft-square platforms, 5,000 lb x 1 lb and 10,000 lb x 2 lb capacities, NTEP-approved IP67 waterproof anti-corrosion shear beam load cells, 3/16”-thick checkered steel deck, 2.2-in/5.6-cm diameter rubber feet, and durable structural steel channel.
- 3/16-Inch-Thick Checkered Steel Deck Protection
- 4 x 4 ft Checkered Steel Deck Platform
- 5000 lb x 1 lb or 10000 lb x 2 lb Capacity
- Durable Structural Steel Channel
- High-Quality Economical Floor Scales
- Industrial Tan Powder Paint
- Load Cell Feet Swivel to Find Level Ground
- NTEP Legal for Trade
- NTEP-Approved Alloy Steel Shear Beam Load Cells
- Ramps Available (model EH-501E)
- Rubber Load Cell Footings
- Side-Access Junction Box
|
|
Other Detecto EH-Series Echelon Legal For Trade Floor Scales
|
Specifications
| MODEL |
EH-544 |
EH-1044 |
| Capacity x Readability |
5,000 x 1 lb |
10,000 x 2 lb |
| Legal for Trade |
NTEP: 15-085 |
| Platform Size |
4 ft x 4 ft |
4 ft x 4 ft |
| Indicator |
Detecto Model 185 Digital Weight Indicator - 1 LCD display |
| Enclosure Size |
7.7 " W x 4.7" H x 2.6" D
19.6 cm W x 11. 9 cm H x 6. 6 cm D |
| Indicator Housing |
IP66-rated ABS indicator enclosure with versatile stainless steel wall or desktop mounting bracket |
| Temperature Range |
14 °F to 104 °F / -10 °C to 40 °C |
| Display: |
Bold 1-inch/25-mm high backlit LCD |
| Standard I/O |
(1) bi-directional RS-232 port |
| Standard Features |
Piece Counting, Millivolt Display Diagnostic Function |
| Weighing Units |
Pounds(lb), Ounces (oz), Kilograms (kg) |
|
|
|
|
|
|
| |
|
|
|
|
)
