Imada SV-05S Micro-Movement Precision Wheel Test Stand with Distance Meter
 |
- One stand does both compression (push) and tension (pull) tests
- Reduced backlash and fine movement for highly precise measurements
- Stroke 2.75" (travel distance per knob rotation 0.9"/22.5mm)
- Maximum Load 4.4 lbs (2 kg)
The SV-05S Micro-Movement Test Stand is designed for small deflection measurements such as membrane switches and other small micro switches. The minimal backlash is ideal for bi-directional testing where both the compression and tension measurements are made during the same test. The standard model SV-05S includes a highly accurate digital distance meter. Both models accept any Imada force gauge with a maximum capacity of 4.4 lbs (2 kg).
Distance Meter Specifications
| Display | Push button for inch/mm, zero set and on/off |
|---|---|
| Resolution | 0.0005"/0.01 mm |
| Accuracy | 0.1% of reading or 0.005"/0.1mm, whichever is greater |
Optional Data Buttons and Data Software
Imada DB-Series data input buttons work with Imada
SW software to automate data collection from Imada force
or torque gauges. Enter peak measurements into the spreadsheet
and "zero" the gauge with a touch of the button.
Minimize computer time and mouse usage
