The Defender 6000 Series Extreme Washdown Bench Scale is specifically designed for food, chemical and pharmaceutical applications, including production and packaging. Defender 6000 handles the most demanding applications with 316 stainless steel platform and frame, and hermetically-sealed stainless steel IP69K load cell. Defender 6000 meets metrological approvals, NSF listing, and supporting HACCP systems.
Industrial Scales >> Ohaus Scales

Ohaus Defender 6000 I-D61XW Hybrid Washdown Bench Scales

Have Questions?

email Us

Our Staff will be glad to help


Legal For Trade	Canada Measurement

	Specifications Chart
	Specifications Chart
	Specifications Chart

Dims

Washdown Bench Scale for Standard Industrial Applications The Defender 6000 series hybrid washdown bench scale is ideal for a multitude of applications, including production and packaging. Handles demanding applications with the Defender 6000 indicator and Defender 5000 W series washdown base. The Defender 6000 hybrid is designed to simplify demanding industrial and commercial applications.

Unique Features Include:

Defender 6000 Hybrid stands up to harsh cleaning in processing and packaging environments with IP68 immersion/IP69K protected indicator, 304 stainless steel construction and IP67 stainless steel load cell.
Large digits on a bright backlit LCD or white LED display quickly and clearly show results for fast processing. Color bar in i-DT61PW can be used for quick checking of package weights for fast go/no-go alert. Configurable color bar matrix in i-DT61XWE can be used for detailed checking of package weights to ensure compliance.
Durably constructed with a stainless steel platform, frame, IP67 loadcell and IP68/69K indicator, Defender 6000 hybrid meets NTEP and Measurement Canada approvals.

Compliance Metrology: NTEP (Indicator: CC 20-043, Platforms: CC 18-077) Class lll, Measurement Canada (Indicator: NoA AM-6159, Platforms: NoA AM-6107)
Product Safety: CAN/CSA C22.2 61010-1; UL61010-1; IEC/EN 61010-1
Electromagnetic Compatibility: FCC Part 15 Class A; Canada ICES-003 Class A; IEC/EN 61326-1 Class B, basic environments
Food Safety: ANSI/NSF 169 (Indicator only)
Ingress Protection: IEC 60529 – IP68 (Indicator), ISO 20653 – IP69K (Indicator), IEC 60529 - IP67 (Load cell)
Compliance Marks: CSA, CE
Other: WEEE, RoHS

Ohaus Defender 6000 i-DT61XWE
Washdown Bench Scales

FREE UPS Ground Shipping
(within the 48 continental US States)

See Lowest Price In Cart

	Ohaus 30412537 WiFi/BT Dongle, OHAUS (Requires 30424406), add $305.10
	Ohaus 30424404 2nd RS232/RS485/USB, TD523, add $221.40
	Ohaus 30429666 Ethernet Kit, D522, add $221.40
	Ohaus 30424403 Analog Output Kit, TD52, add $221.40
	Ohaus 30097591 Discrete I/O Kit, 2In/4Out, R71, add $206.10
	Ohaus 30424021 Light Tower, R-Y-G, IP65, 24VDC (requires 30097591), add $256.50
	Ohaus 80500552 RS232 Cable, PC 9 Pin To Defender 5000 & 7000 with T71XW, T51XW, add $238.50
	Ohaus 30379716 M16 Gland with Ferrite, to TD52, add $29.70
	Ohaus 80500503 - Alibi Memory Kit Option, T71 for Defender 7000 and Ranger 7000 Series, add $162.90
	Ohaus 30424409 LC Extension Cable, 9 meters, D521, add $221.40
	Ohaus 30616409 304 Stainless Steel Wheel Kit for Defender Series , add $221.40

More info

Column Mount Bench Scales (Stainless Steel Indicator)

Model	i-D61XWE2WQS6 30631706	i-D61XWE5WQS6 30631707	i-D61XWE12WQS6 30631718	i-D61XWE12WQR6 30631719	i-D61XWE25WQR6 30631720	i-D61XWE50WQR6 30631721	i-D61XWE25WQL7 30631722	i-D61XWE50WQL7 30631723	i-D61XWE125WQL7 30631724
Price	$1,545.10	$1,545.10	$1,545.10	$1,666.55	$1,666.55	$1,666.55	$2,288.52	$2,288.52	$2,288.52
Capacity x Readability	5 lb x 0.0002 lb	10 lb x 0.0005 lb	25 lb x 0.001 lb	25 lb x 0.001 lb	50 lb x 0.002 lb	100 lb x 0.005 lb	50 lb x 0.002 lb	100 lb x 0.005 lb	250 lb x 0.01 lb
	2.5 kg x 0.1g	5 kg x 0.2 g	12.5 kg x 0.5 g	12.5 kg x 0.5 g	25 kg x 1g	50 kg x 2 g	25 kg x 1g	50 kg x 2 g	125 kg x 5 g
	80 oz x 0.005 oz	160 oz x 0.01 oz	400 oz x 0.02 oz g	400 oz x 0.02 oz	800 oz x 0.05 oz	1600 oz x 0.1 oz	800 oz x 0.05 oz	1600 oz x 0.1 oz	4000 oz x 0.2 oz
Maximum Displayed Resolution	1:25,000	1:25,000	1:25,000	1:25,000	1:25,000	1:25,000	1:25,000	1:25,000	1:25,000
Linearity/Repeatability	+2d	+2d	+2d	+2d	+2d	+2d	+2d	+2d	+2d
Legal for Trade Capacity x Readability	5 lb x 0.001 lb	10 lb x 0.002 lb	25 lb x 0.005 lb	25 lb x 0.005 lb	50 lb x 0.01 lb	100 lb x 0.02 lb	50 lb x 0.01 lb	100 lb x 0.02 lb	250 lb x 0.05 lb
	2.5 kg x 0.5 g	5 kg x 1 g	12.5 kg x 5 g	12.5 kg x 5 g	25 kg x 5 g	50 kg x 10 g	25 kg x 5 g	50 kg x 10 g	125 kg x 50 g
	80 oz x 0.02 oz	160 oz x 0.05 oz	400 oz x 0.1 oz	400 oz x 0.1 oz	800 oz x 0.2 oz	1600 oz x 0.5 oz	800 oz x 0.2 oz	1600 oz x 0.5 oz	4000 oz x 1 oz
Legal For trade	NTEP Indicator: CC# 20-043 Class lll Platforms: CC 18-077) Class lll Canada Indicator: NoA AM-6159 Platforms: NoA AM-6107
Maximum Certified Resolution	1:5,000
Pan Size	10 x 10 in	10 x 10 in	10 x 10 in	12 x 12 in	12 x 12 in	12 x 12 in	18 x 18 in	18 x 18 in	18 x 18 in
Indicator	i-DT61XWE
Indicator Construction	316 Stainless steel housing, 316 stainless steel bracket
IP Rating	IP68 immersion/ IP69K washdown
Display	6-digit, 7-segment white LED, 20 mm high digits
Check Indicator	3 color (red, green, orange) 8x16 dot matrix LED
Weighing Units	Kilogram, Gram, Pound, Ounce, Pound: Ounce
Application Modes	Basic weighing, Percent weighing, Check weighing/percent, Dynamic weighing, Filling weighing, Counting
Keyboard	6 function keys + 12 alpha numeric capacitive keypad
Stabilization Time	Within 2 second
Power	100-240 VAC / 50/60 Hz Universal Power Supply, hardwired
Interface	Standard: RS232, USB Host Optional: Ethernet, Wi-Fi/Bluetooth, 2nd RS232/RS485/USB, Analog output, 2 In/4 Out Discrete I/O
Column	13.8 in / 350 mm stainless steel						26.8 in / 680 mm stainless steel
Base Construction	Stainless steel removable weighing platform with stainless steel frame, silicon-sealed IP67 stainless steel loadcell
Safe Overload Capacity	150% of maximum capacity
Operating Temperature Range	14^oF to 104^oF / -10^oC to 40^oC
Scale Dimensions (A x B x C x D x E x F)	10 x 10 x 2.9 x 1.8 x 24.1 x 15.1 in 254 x 254 x 74 x 45 x 613 x 383 mm			12 x 12 x 3.7 x 2.4 x 24.3 x 17.4 in 305 x 305 x 95 x 60 x 617 x 442 mm			18 x 18 x 4.3 x 2.8 x 37.3 x 24.7 in 457 x 457 x 110 x 70 x 947 x 627 mm
Shipping Dimensions (L x W x H)	18.9 x 17.5 x 14.3 in 480 x 445 x 363 mm						39.1 x 26.8 x 9.25 in 994 x 680 x 235 mm
Approx. Net Weight	22.1 lb / 10 kg			26.5 lb / 12 kg			44.1 lb / 20 kg
Approx. Shipping Weight	26.5 lb / 12 kg			30.9 lb / 14 kg			50.7 lb / 23 kg

Column Mount Bench Scales (Polycarbonate Plastic Indicator)

Model	i-D61PW2WQS6 30626679	i-D61PW5WQS6 30626680	i-D61PW12WQS6 30626681	i-D61PW12WQR6 30626682	i-D61PW25WQR6 30626683	i-D61PW50WQR6 30626684	i-D61PW25WQL7 30631703	i-D61PW50WQL7 30631704	i-D61PW125WQL7 30631705
Price	$1,347.14	$1,347.14	$1,347.14	$1,469.29	$1,469.29	$1,469.29	$2,076.52	$2,076.52	$2,076.52
Capacity x Readability	5 lb x 0.0002 lb	10 lb x 0.0005 lb	25 lb x 0.001 lb	25 lb x 0.001 lb	50 lb x 0.002 lb	100 lb x 0.005 lb	50 lb x 0.002 lb	100 lb x 0.005 lb	250 lb x 0.01 lb
	2.5 kg x 0.1g	5 kg x 0.2 g	12.5 kg x 0.5 g	12.5 kg x 0.5 g	25 kg x 1g	50 kg x 2 g	25 kg x 1g	50 kg x 2 g	125 kg x 5 g
	80 oz x 0.005 oz	160 oz x 0.01 oz	400 oz x 0.02 oz g	400 oz x 0.02 oz	800 oz x 0.05 oz	1600 oz x 0.1 oz	800 oz x 0.05 oz	1600 oz x 0.1 oz	4000 oz x 0.2 oz
Maximum Displayed Resolution	1:25,000	1:25,000	1:25,000	1:25,000	1:25,000	1:25,000	1:25,000	1:25,000	1:25,000
Linearity/Repeatability	+2d	+2d	+2d	+2d	+2d	+2d	+2d	+2d	+2d
Legal for Trade Capacity x Readability	5 lb x 0.001 lb	10 lb x 0.002 lb	25 lb x 0.005 lb	25 lb x 0.005 lb	50 lb x 0.01 lb	100 lb x 0.02 lb	50 lb x 0.01 lb	100 lb x 0.02 lb	250 lb x 0.05 lb
	2.5 kg x 0.5 g	5 kg x 1 g	12.5 kg x 5 g	12.5 kg x 5 g	25 kg x 5 g	50 kg x 10 g	25 kg x 5 g	50 kg x 10 g	125 kg x 50 g
	80 oz x 0.02 oz	160 oz x 0.05 oz	400 oz x 0.1 oz	400 oz x 0.1 oz	800 oz x 0.2 oz	1600 oz x 0.5 oz	800 oz x 0.2 oz	1600 oz x 0.5 oz	4000 oz x 1 oz
Legal For trade	NTEP Indicator: CC# 20-043 Class lll Platforms: CC 18-077) Class lll Canada Indicator: NoA AM-6159 Platforms: NoA AM-6107
Maximum Certified Resolution	1:5,000
Pan Size	10 x 10 in	10 x 10 in	10 x 10 in	12 x 12 in	12 x 12 in	12 x 12 in	18 x 18 in	18 x 18 in	18 x 18 in
Indicator	i-DT61PW
Indicator Construction	Polycarbonate plastic housing, 316 stainless steel bracket
IP Rating	IP68 immersion/ IP69K washdown
Display	6-digit, 7-segment white LED, 20 mm high digits
Check Indicator	3 color (red, green, orange) 8x16 dot matrix LED
Weighing Units	Kilogram, Gram, Pound, Ounce, Pound: Ounce
Application Modes	Basic weighing, Percent weighing, Check weighing/percent, Dynamic weighing, Filling weighing, Counting
Keyboard	6 function mechanical keys
Stabilization Time	Within 1 second
Power	6 x D type cell battery
Interface	Standard: RS232, USB Host Optional: Ethernet, Wi-Fi/Bluetooth, 2nd RS232/RS485/USB, Analog output, 2 In/4 Out Discrete I/O
Column	13.8 in / 350 mm stainless steel						26.8 in / 680 mm stainless steel
Base Construction	Stainless steel removable weighing platform with stainless steel frame, silicon-sealed IP67 stainless steel loadcell
Safe Overload Capacity	150% of maximum capacity
Operating Temperature Range	14^oF to 104^oF / -10^oC to 40^oC
Scale Dimensions (A x B x C x D x E x F)	10 x 10 x 2.9 x 1.8 x 23.6 x 15.1 in 254 x 254 x 74 x 45 x 600 x 383 mm			12 x 12 x 3.7 x 2.4 x 23.8 x 17.4 in 305 x 305 x 95 x 60 x 604 x 442 mm			18 x 18 x 4.3 x 2.8 x 36.8 x 24.7 in 457 x 457 x 110 x 70 x 934 x 627 mm
Shipping Dimensions (L x W x H)	18.9 x 17.5 x 14.3 in 480 x 445 x 363 mm						339.1 x 26.8 x 9.25 in 994 x 680 x 235 mm
Approx. Net Weight	22.1 lb / 10 kg			26.5 lb / 12 kg			44.1 lb / 20 kg
Approx. Shipping Weight	26.5 lb / 12 kg			30.9 lb / 14 kg			50.7 lb / 23 kg

Front Mount Bench Scales (Polycarbonate Plastic Indicator)

Model	i-D61PW2WQS5 30631725	i-D61PW5WQS5 30631726	i-D61PW12WQS5 30631727	i-D61PW12WQR5 30631728	i-D61PW25WQR5 30631729	i-D61PW50WQR5 30631730	i-D61PW25WQL5 30572969	i-D61PW50WQL5 30572970	i-D61PW125WQL5 30572971
Price	$1,480.52	$1,480.52	$1,480.52	$1,594.24	$1,594.24	$1,594.24	$1,992.98	$1,992.98	$1,992.98
Capacity x Readability	5 lb x 0.0002 lb	10 lb x 0.0005 lb	25 lb x 0.001 lb	25 lb x 0.001 lb	50 lb x 0.002 lb	100 lb x 0.005 lb	50 lb x 0.002 lb	100 lb x 0.005 lb	250 lb x 0.01 lb
	2.5 kg x 0.1g	5 kg x 0.2 g	12.5 kg x 0.5 g	12.5 kg x 0.5 g	25 kg x 1g	50 kg x 2 g	25 kg x 1g	50 kg x 2 g	125 kg x 5 g
	80 oz x 0.005 oz	160 oz x 0.01 oz	400 oz x 0.02 oz g	400 oz x 0.02 oz	800 oz x 0.05 oz	1600 oz x 0.1 oz	800 oz x 0.05 oz	1600 oz x 0.1 oz	4000 oz x 0.2 oz
Maximum Displayed Resolution	1:25,000	1:25,000	1:25,000	1:25,000	1:25,000	1:25,000	1:25,000	1:25,000	1:25,000
Linearity/Repeatability	+2d	+2d	+2d	+2d	+2d	+2d	+2d	+2d	+2d
Legal for Trade Capacity x Readability	5 lb x 0.001 lb	10 lb x 0.002 lb	25 lb x 0.005 lb	25 lb x 0.005 lb	50 lb x 0.01 lb	100 lb x 0.02 lb	50 lb x 0.01 lb	100 lb x 0.02 lb	250 lb x 0.05 lb
	2.5 kg x 0.5 g	5 kg x 1 g	12.5 kg x 5 g	12.5 kg x 5 g	25 kg x 5 g	50 kg x 10 g	25 kg x 5 g	50 kg x 10 g	125 kg x 50 g
	80 oz x 0.02 oz	160 oz x 0.05 oz	400 oz x 0.1 oz	400 oz x 0.1 oz	800 oz x 0.2 oz	1600 oz x 0.5 oz	800 oz x 0.2 oz	1600 oz x 0.5 oz	4000 oz x 1 oz
Legal For trade	NTEP Indicator: CC# 20-043 Class lll Platforms: CC 18-077) Class lll Canada Indicator: NoA AM-6159 Platforms: NoA AM-6107
Maximum Certified Resolution	1:5,000
Pan Size	10 x 10 in	10 x 10 in	10 x 10 in	12 x 12 in	12 x 12 in	12 x 12 in	18 x 18 in	18 x 18 in	18 x 18 in
Indicator	i-DT61PW
Indicator Construction	Polycarbonate plastic housing, 316 stainless steel bracket
IP Rating	IP68 immersion/ IP69K washdown
Display	6-digit, 7-segment white LED, 20 mm high digits
Check Indicator	3 color (red, green, orange) 8x16 dot matrix LED
Weighing Units	Kilogram, Gram, Pound, Ounce, Pound: Ounce
Application Modes	Basic weighing, Percent weighing, Check weighing/percent, Dynamic weighing, Filling weighing, Counting
Keyboard	6 function mechanical keys
Stabilization Time	Within 1 second
Power	6 x D type cell battery
Interface	Standard: RS232, USB Host Optional: Ethernet, Wi-Fi/Bluetooth, 2nd RS232/RS485/USB, Analog output, 2 In/4 Out Discrete I/O
Base Construction	Stainless steel removable weighing platform with stainless steel frame, silicon-sealed IP67 stainless steel loadcell
Safe Overload Capacity	150% of maximum capacity
Operating Temperature Range	14^oF to 104^oF / -10^oC to 40^oC
Scale Dimensions (A x B x C x D x E x F)	10 x 10 x 2.9 x 1.8 x 5.1 x 20.8 in 254 x 254 x 74 x 45 x 129 x 529 mm			12 x 12 x 3.7 x 2.4 x 5.1 x 23.1 in 305 x 305 x 95 x 60 x 129 x 588 mm			18 x 18 x 4.3 x 2.8 x 5.1 x 28.9 in 457 x 457 x 110 x 70 x 129 x 734 mm
Shipping Dimensions (L x W x H)	18.9 x 17.5 x 14.3 in 480 x 445 x 363 mm						339.1 x 26.8 x 9.25 in 994 x 680 x 235 mm
Approx. Net Weight	22.1 lb / 10 kg			24.3 lb / 11 kg			39.7 lb / 18 kg
Approx. Shipping Weight	26.5 lb / 12 kg			28.7 lb / 13 kg			46.3 lb / 21 kg

Accessories
Wi-Fi/Bluetooth Dongle i-DT61XW. . . . . . . . . . 30412537
Analog Output Kit i-DT61XW. . . . . . . . . . . . . . . 30424403
2nd RS232/RS485/USB
Device Kit i-DT61XW. . . . . . . . . . . . . . . . . . . . . . . 30424404
LC Extension Cable, 9 meters. . . . . . . . . . . . . . . 30424409
M16 Gland with Ferrite. . . . . . . . . . . . . . . . . . . . . 30379716
Light Tower, 3 Colors, 243mm, IP65
(Requires 30097591). . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 30424021
Discrete I/O with Relays
(2 In/4 Out) i-DT61XW. . . . . . . . . . . . . . . . . . . . . . 30097591
Ethernet Kit i-DT61XW. . . . . . . . . . . . . . . . . . . . . 30429666
External Power Bank Holder i-DT61XW
(requires external USB power bank). . . . . . . . . . . . . . . . 30572907
Cable RS232 i-DT61XW. . . . . . . . . . . . . . . . . . . . . 80500552
Column Kit, 13.8 in / 35 cm, SST, D52. . . . . . . 30424413
Column Kit, 26.8 in / 68 cm, SST, D52. . . . . . . . 30424414
Column Kit, 38.6 in / 98 cm, SST, D52. . . . . . . . 30424415
Front Mounting Kit 316 SS i-DT61PW. . . . . . . 30424024
IR communication Kit i-DT61PW. . . . . . . . . . . . 30572910
Wheel Kit SS Defender Series. . . . . . . . . . . . . . . 30616409
Alibi Memory i-DT61XW. . . . . . . . . . . . . . . . . . . . 80500503
